Drone Compare Wingtra RAY vs Quantum Systems Trinity Pro
Flight Time vs Price
Effective Megapixels vs Price i
Key Differences
- Price (US)$21,193 vs $23,789.94
- WeightN/A vs 4,750 g
- Max Flight Time59 min vs 90 min
- Max Speed22 m/s vs 20 m/s
- Megapixels (SURVEY61)61 MP vs 128 MP
- Megapixels (INSPECT)61 MP vs N/A
- Sensor Size (SURVEY61)Full Frame vs Medium Format
- Sensor Size (INSPECT)Full Frame vs APS-C
- Field of View (MAP61)103.4° vs N/A
No reviews yet — be the first!
| Specification | Wingtra RAY | Quantum Systems Trinity Pro |
|---|---|---|
| Identity | ||
| Manufacturer | Wingtra | Quantum Systems |
| Rating | — | — |
| Known Issues | — | — |
| Release Date | Jun 30, 2025 | May 2, 2023 |
| Availability | Available | Available |
| EU Drone Class | C3, C6 | None |
| US Procurement | — | — |
| Platform Type | VTOL | VTOL |
| Pricing | ||
| Price (EU) | €18,300 | €20,729 |
| Price (US) | $21,193 | $23,789.94 |
| Links | ||
| Product Page | https://wingtra.com/ray | https://quantum-systems.com/trinity-pro/ |
| Shop Page | — | https://www.dronenerds.com/products/quantum-systems-trinity-pro-americas |
| Physical | ||
| Weight | — | 4,750 g |
| Max Takeoff Weight | 5,200 g | 5,750 g |
| Folded Dimensions | 1,250 × 680 × 340 mm | 1,002 × 830 × 270 mm |
| IP Rating | IP53 | IP55 |
| Operating Temperature | -10°C to 40°C | -12°C to 50°C |
| Flight | ||
| Max Flight Time | 59 min | 90 min |
| Max Speed | 22 m/s | 20 m/s |
| Max Speed (EU) | 22 m/s | 20 m/s |
| Max Ascent Speed | 8.8 m/s | — |
| Max Descent Speed | 6 m/s | — |
| Max Flight Distance | — | — |
| Max Altitude | 5,000 m | 5,500 m |
| Wind Resistance | 18 m/s | 18 m/s |
| Payload | ||
| Camera | ||
| Camera 1 | MAP61 | Sony ILX-LR1 |
| Sensor Size | Full Frame | Full Frame |
| Pixel Binning | — | — |
| Megapixels | 61 MP | 61 MP |
| Focal Length | 17mm | 24mm |
| Aperture | — | f/2.8 |
| Zoom | — | — |
| Mechanical Shutter | ✓ Yes | ✓ Yes |
| ISO Range | — | — |
| Shutter Speed | — | — |
| Stabilization Type | — | — |
| Max Photo Resolution | 9504x6336 | 9504x6336 |
| Image Formats | — | RAW (Proprietary), JPEG, HEIF |
| AEB | — | — |
| AEB EV Bias | — | — |
| Panorama Modes | — | — |
| Panorama Formats | — | — |
| Video Resolutions | — | — |
| Video Codec | — | — |
| Video Formats | — | — |
| Color Profiles | — | — |
| Camera 2 | SURVEY61 | Phase One P5 |
| Camera 3 | INSPECT | Oblique D2M |
| Gimbal | ||
| Gimbal | ||
| Gimbal 1 | — | — |
| Stabilization Axes | — | — |
| Tilt Range | — | — |
| Pan Range | — | — |
| Roll Range | — | — |
| Navigation | ||
| GNSS | GPS, GLONASS, Galileo, BeiDou | Galileo, GPS, GLONASS, BeiDou |
| Hover Accuracy | — | — |
| RTK | — | No |
| RTK Horizontal Accuracy | — | — |
| RTK Vertical Accuracy | — | — |
| Recovery Mode | — | — |
| Obstacle Sensors | — | Downward |
| Obstacle Avoidance | — | Active (Avoidance) |
| Sensing Technology | — | LiDAR |
| Sensing Technology (Add-on) | — | — |
| Transmission | ||
| Transmission Protocol | — | — |
| Max Range (CE) | 10 km | 7.5 km |
| Max Range (FCC) | 10 km | 7.5 km |
| Live View Quality | — | — |
| Cellular | ✓ Yes | ✓ Yes |
| App | ||
| Flight App | — | — |
| Supported OS | — | — |
| Resume from Waypoint | — | ✓ Yes |
| Mission Types | — | Waypoint, Area, Corridor, Oblique, Linear, Geometric |
| Features | ||
| Internal Storage | — | — |
| Max MicroSD | — | — |
| ActiveTrack | — | — |
| Hyperlapse | — | — |
| Night Scene | — | — |
| NIR Light | — | — |
| Laser Rangefinder | — | — |
| Laser Rangefinder Range | — | — |
| Remote ID | Built-in | Built-in |
| ADS-B Receiver | — | ✓ Yes |
| Data Encryption | — | — |
| Expansion Port | — | — |
| SDK Support | — | — |
| Mapping | ||
| Waypoints | — | ✓ Yes |
| Terrain Follow | — | ✓ Yes |
| Raw GNSS Logging | — | — |
| Cargo | ||
| Delivery Mode | — | — |
| Max Range (Loaded) | — | — |
| Max Flight Time (Loaded) | — | — |
| Accessories | ||
| Battery | ||
| Propeller | ||
| Remote Controller | ||
| Charger | ||
